V2 FLEXY2 230V

V2 FLEXY2 Control Board in Dubai, Sharjah, Ajman, Abu Dhabi UAE.

• FLEXY2 230V analogue control unit for swing gates and sliding gates.
• FLEXY2 : 12G035-230V - for 230V motors.

Technical Features:

• Power supply vhz : 230 / 50 V / Hz.
• Maximum motor load : 700 W.
• Maximum load on 24 Vac accessories : 3 W.
• Dimensions : 170 x 185 x 70 mm.
• Weight : 800 g.

FLEXY2 STRENGTHS

• Adjustment and programming by trimmer and dip-switch
• 230V power supply for 2 single-phase motors
• Built-in receiver (433,92 MHz)
• Possibility to store up to 240 Personal Pass transmitter
• RJ45 connector to connect the control unit to the programmer PROG2 via standard network cable (UTP)
• Start, pedestrian start and stop controls from transmitter
• Open/close limit switch inputs
• 230V flashing light output (use flashing lights with intermittence)
• Courtesy light output (also controllable by transmitter)
• Safety device test before any opening
• Leaf slow-down function in limit switch area to prevent noisy closures and rebounds
• Monitoring of input status shown by LEDs
